Product Description

HeJin Ten-Station Automatic High-Pressure Relay Gas Filling and Sealing Machine is designed for the automated gas filling and sealing process of customized high-pressure relays. With a ten-station working configuration, the system is developed for manufacturers seeking a more consistent, efficient, and repeatable production process for sealed relay components.

As a direct manufacturer of Auto Parts Test Equipment, HeJin provides equipment development, mechanical design, manufacturing, commissioning, and technical support from one source.

Product Introduction

Ten-Station Automatic Gas Filling and Sealing for High-Pressure Relay Manufacturing

A reliable relay starts long before it reaches the final inspection stage.

For customized high-pressure relays, the internal gas environment and sealing quality can directly influence the consistency and long-term reliability of the finished component. Manual gas filling and sealing processes can introduce differences between operators, particularly when production volume increases or product specifications change.

The HeJin Ten-Station Automatic High-Pressure Relay Gas Filling and Sealing Machine was developed to address this production challenge.

Designed specifically for the gas filling and sealing of customized high-pressure relay products, the machine integrates multiple working stations into an automated production process. The ten-station configuration allows several workpieces to be processed within the same production cycle, helping manufacturers improve workflow continuity while reducing unnecessary manual intervention.

Main Features

• 1. Ten-Station Production Configuration

  The machine adopts a 10-station working configuration, allowing multiple relay workpieces to enter the production process in a coordinated manner.

  This configuration is particularly useful for manufacturers looking to increase production efficiency without simply adding more individual machines.

• 2. Designed for Customized High-Pressure Relays

  High-pressure relay structures are not always identical.

  Different products may have different filling ports, sealing structures, dimensions and process requirements.

  HeJin can develop corresponding fixtures and process configurations according to the customer's actual workpiece.

• 3. Automatic Gas Filling Process

  The equipment is designed to automate the gas filling operation required during relay production, helping maintain a more consistent manufacturing process.

• 4. Automatic Sealing and Cutting

  After the required gas filling process is completed, the equipment performs the corresponding sealing/cutting operation according to the configured process.

  This reduces unnecessary manual operations and helps improve process consistency.

• 5. Multi-Station Process Coordination

  Multiple stations work as part of an integrated production system rather than operating as isolated manual workbenches.

Technical Parameters

Main Functions

Core Technology

Automated Gas Filling + Sealing Process Integration

The core concept of the machine is to combine the gas filling and subsequent sealing operation into a coordinated automated production sequence.

For customized relay manufacturing, the process can generally be understood as:

Workpiece Loading → Positioning → Gas Filling → Filling Completion → Sealing/Cutting → Workpiece Unloading

The key engineering challenge is not simply automation.

It is the ability to maintain:

• Repeatable positioning
• Stable process timing
• Consistent gas filling conditions
• Controlled sealing action
• Reliable fixture alignment
• Coordinated multi-station operation

This is where customized mechanical design and process engineering become important.

Product detail images

FAQ

• 1. What is this ten-station relay machine used for?

  It is designed primarily for the automated gas filling, sealing and cutting process of customized high-pressure relay products.

• 2. How many relays can the machine process?

  The machine uses a 10-station configuration. Actual production capacity depends on the configured process cycle, workpiece structure and loading/unloading method.

• 3. Can the machine be customized for our relay?

  Yes. Customized relay products can require dedicated fixtures and process configurations. HeJin can develop the equipment according to customer drawings, samples and production requirements.

• 4. Is the machine suitable for automotive relay manufacturing?

  Yes. The equipment is positioned for customized relay production and fits within the broader Auto Parts Test Equipment and automotive component manufacturing ecosystem.

• 5. Does the machine perform leak testing?

  The primary purpose of this machine is gas filling and sealing/cutting. If final hermeticity testing is required, HeJin can provide dedicated helium leak testing equipment as a downstream inspection solution. HeJin already offers multi-station relay helium leak detection systems.

• 6. Can HeJin design a customized fixture?

  Yes. Fixture design can be developed according to the relay's dimensions, structure and process requirements.
