High-Precision Carton Compression Tester with 200 Times/Second Sampling and 0.001 mm Resolution for Packaging Strength Testing

Brand Name:	He Jin
Model Number:	SH-16
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	T/T,L/C
Supply Ability:	5 set /month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration Certificate(cost additional)

Sampling Frequency:

200 Times/second

Displacement Resolution:

0.001 Mm

Load Cell Accuracy:

±0.5% F.S.

Compression Platen Parallelism:

≤0.05 Mm

Power Supply:

AC 220V ±10%, 50/60Hz

Drive System:

High-precision Servo Motor With Quiet Operation

Packaging Details:

Plywood

Highlight:

200 times/second sampling Carton Compression Tester

0.001 mm resolution Carton Compression Tester

±0.5% F.S. load cell accuracy Carton Compression Tester

Product Description

Carton Compression & Hold-Pressure Tester | Impact Testing Machine for Packaging Strength

Product Description

The Carton Compression and Hold-Pressure Tester by HeJin, a trusted original manufacturer, is designed to measure the structural strength and durability of corrugated cartons and packaging boxes. Built for precision, consistency, and long-term stability, this machine helps companies evaluate packaging performance under real-world compression forces—ensuring products remain safe throughout storage, stacking, and transportation.

Product Features

High-precision servo motor control ensuring smooth and stable compression movement.
Automatic data acquisition including force value, displacement, deformation, and holding curves.
Large test area designed to accommodate multiple carton sizes.
Long hold-pressure capability for simulating long-term warehouse stacking.
Impact testing extension support (aligned with keyword classification Impact Testing Machine).
Overload & emergency stop protection for operator safety.
Durable steel structure for long-term industrial use.

International Standards

ISO 12048 – Compression and stacking tests on complete, filled transport packages
ASTM D642 – Standard Test Method for Determining Compressive Resistance of Shipping Containers
TAPPI T804 – Compression strength of fiberboard shipping containers
ISO 2872 – Packaging – Complete, filled transport packages – Compression test
ISO 2234 – Packaging – Stacking test using static load
GB/T 4857.4-2008 – Package compression resistance test
ISTA Series 3A / 6A – Packaging strength and impact simulation requirements

Technical Parameters

Technical Parameter	Value
Compression Force Range	0–50 kN (customizable)
Accuracy	±0.5% FS
Resolution	1 N
Test Space	1000 * 1000 * 1000 mm
Compression Speed Range	1–300 mm/min
Speed Accuracy	±1%
Hold-Pressure Time	1–9999 s adjustable
Test Modes	Compression / Hold-Pressure / Impact Compression
Data Output	USB, LAN, CSV/Excel export
Force Sensor Type	High-precision load cell
Power Supply	AC 220V / 50–60Hz
Operation Interface	7–10 inch touchscreen
Structure Material	Reinforced steel frame
Safety Protection	Emergency stop + overload shutdown
Optional Add-ons	Larger platform, extended height, dual-zone sensors

Operating Procedure

Place the carton or packaging sample on the test platform.
Select the test mode: compression, hold-pressure, or impact compression.
Input sample dimensions and test parameters on the touchscreen.
Start the test—system performs automatic pressure application and data collection.
View real-time compression curves and force-time graphs.
Export test data or print test reports.
Remove the sample and clean the test area.
