15KW Helium Recovery Rate 90% Helium Recovery Machine For Leak Testing Equipment

Minimum Order Quantity : 1 Set Price : Negotiatable
Packaging Details : Plywood Delivery Time : 90 Days
Payment Terms : L/C, T/T Supply Ability : 10 Set per month
Place of Origin: China Brand Name: HeJin
Certification: Calibration Certificate(Cost Additional) Model Number: HJ102

Detail Information

Dimension: ≦2200X2000X2500mm Helium Recovery Rate: ≥90%
Energy Consumption: 15KW Recycling Time: ≤3s
Helium Charging Pressure: 0.5~0.25mpa Helium Concentration Accuracy: ±5%
High Light:

15KW Helium Recovery Machine

,

Leak Testing Equipment Helium Recovery Machine

,

3s Recycling Time Helium Recovery Machine

Product Description

15KW Helium Recovery Rate 90% Helium Recovery Machine For Leak Testing Equipment



Structural Features with Leak Testing Equipment:

(1) Design Philosophy: The equipment is designed with the perfect integration of advancedness, rationality, reliability, practicability, safety, and ease of maintenance. Every detail has been carefully considered to ensure the efficient and stable operation of the equipment.



(2) Environmental Protection and Cleanliness Assurance: To ensure that the client's clean inspection workshop is not contaminated by helium, the equipment undergoes strict helium leak detection during manufacturing at all connections, thereby guaranteeing that no helium leakage occurs during the operation of the entire equipment.



(3) Intelligent Control System: The system is precisely controlled by PLC and equipped with an intuitive and user-friendly touchscreen interface. This interface features a main menu and membrane buttons, allowing users to conveniently perform parameter setting, production process control, production status monitoring, fault alarm and self-diagnosis operations, while also supporting manual maintenance functions.



Technical Features with Leak Testing Equipment:

Automatic Helium Replenishment Function: The system possesses an intelligent automatic helium replenishment mechanism. When the total amount of helium in the system drops below the preset threshold, the system will automatically activate an external helium device to replenish helium until the total amount of helium in the system returns to the preset target value, thus ensuring the continuous and stable operation of the system.



Automatic Gas Concentration Monitoring and Alarm: The system is equipped with a high-precision helium concentration monitoring device that can continuously monitor and display the helium concentration value within the system. Once the concentration exceeds or falls below the preset safe range, the system will immediately trigger an alarm mechanism, promptly reminding users to take action to ensure production safety.



Product Parameter with Leak Testing Equipment:

Dimension ≦2200X2000X2500mm
Helium Recovery Rate ≥90% (Helium recovery rate from helium leak detector), No external air or foreign objects mixed into the recovered helium during the recovery process
Energy Consumption 15KW
Recycling Time The recovery time is ≤ 3s, and within 3s, the pressure at the external port of the battery can be evacuated to below 70mbar.

Helium Charging Pressure

0.5~0.25mpa
Helium Concentration Accuracy ±5%

Product Image with Leak Testing Equipment:

15KW Helium Recovery Rate 90% Helium Recovery Machine For Leak Testing Equipment 015KW Helium Recovery Rate 90% Helium Recovery Machine For Leak Testing Equipment 115KW Helium Recovery Rate 90% Helium Recovery Machine For Leak Testing Equipment 2



Our advantage service:

We have our own developing and designing team, which ensure our own technological and innovative products for customers.
For any customers who have new idea about some products, just let us know, we can according to your idea provide a unique design of the products.



Technical support:

All our workers are experienced and skilled.


After sale service:
Our working team and sales teams can guarantee a fast and high efficiency after-sale service for our product sold to everywhere of the global.



About Us:

Guangzhou Hejin Automation Control Technology Co., Ltd. is a modern enterprise specialized in the research and development, manufacturing, and sales of technology-intensive industrial equipment. The company's leading products include vacuum helium leak detection equipment, automatic brazing machines for gas/liquid filling and recovery systems, lean production lines, and laboratory testing equipment. These products are widely used in industries such as automobiles, refrigeration, power, home appliances, electronics, pharmaceuticals, plumbing, military, and others. Led by Mr. Li Jianhe, an expert with profound knowledge in vacuum and automated testing equipment, the company possesses its own core technology and holds multiple invention and utility model patents. Relying on a high-level talent team, the company has adopted a new production model focused on development and design, assembly and debugging, as well as after-sales service, and provides products that are suitable for customers' specific usage and technical requirements. Since its establishment, the company has introduced various types of specialized equipment to the market, satisfying domestic market demand while also exporting to countries and regions in America, Europe, Asia, and Africa.
