Innovative Leak Testing Equipment For Ceramic Components With Multi-Station Helium Mass Spectrometer

Product Description

 Innovative Leak Testing Equipment for Ceramic Components with Multi-Station Helium Mass Spectrometer

Product Introduction with Leak Testing Equipment:

The multi-station helium mass spectrometer leak detector for ceramic components adopts touch screen and button switch for display and control. Workers place the workpieces manually. It is designed with 2 stations, and each station can detect 4 products simultaneously. Different specifications of products can be detected by changing leak detection tooling. During the leak detection, workers place the workpiece to be tested on the leak detection tooling, which is connected to the leak detector via a leak detection switching valve. After the workpiece is placed and positioned, the cylinder will descend to press the helium gas nozzle against the workpiece. Then the auxiliary pump will be started to evacuate the inside of the workpiece. After that, the leak detector continues to evacuate to clear the background. When the leak detector reaches the background value, the equipment will spray helium gas. The leak detector makes a leak rate judgment based on the penetration of helium gas.

Product Feature with Leak Testing Equipment:

1. After the leak detection is completed, the static point surface of the product will not be pressed, the material (valve metal) will not deform, and the product will not be damaged.

2. To prevent helium poisoning of the equipment, it is equipped with a helium extraction device and exhaust port.

3. The product can automatically alarm if there is air leakage.

4. By replacing the fixture, it can satisfy the automatic leak detection of various products.

Product Parameters with Leak Testing Equipment:

Product Image with Leak Testing Equipment:

Our advantage service:

We have our own developing and designing team, which ensure our own technological and innovative products for customers.
For any customers who have new idea about some products, just let us know, we can according to your idea provide a unique design of the products.

Technical support:

All our workers are experienced and skilled.

After sale service:
Our working team and sales teams can guarantee a fast and high efficiency after-sale service for our product sold to everywhere of the global.


About Us:

Guangzhou Hejin Automation Control Technology Co., Ltd. is a modern enterprise specialized in the research and development, manufacturing, and sales of technology-intensive industrial equipment. The company's leading products include vacuum helium leak detection equipment, automatic brazing machines for gas/liquid filling and recovery systems, lean production lines, and laboratory testing equipment. These products are widely used in industries such as automobiles, refrigeration, power, home appliances, electronics, pharmaceuticals, plumbing, military, and others. Led by Mr. Li Jianhe, an expert with profound knowledge in vacuum and automated testing equipment, the company possesses its own core technology and holds multiple invention and utility model patents. Relying on a high-level talent team, the company has adopted a new production model focused on development and design, assembly and debugging, as well as after-sales service, and provides products that are suitable for customers' specific usage and technical requirements. Since its establishment, the company has introduced various types of specialized equipment to the market, satisfying domestic market demand while also exporting to countries and regions in America, Europe, Asia, and Africa.
