Production Cycle Time ≥500 pcs/h Ceramic Component Multistation Helium Mass Spectrometer Leak Test Equipment
Contact Person : Tessa Huang
Phone Number : +86 18027403449
WhatsApp : +8618027403449
| Minimum Order Quantity : | 1 Set | Price : | Negotiatable |
|---|---|---|---|
| Packaging Details : | Plywood | Delivery Time : | 60 Days |
| Payment Terms : | L/C, T/T | Supply Ability : | 10 Set per month |
| Place of Origin: | China | Brand Name: | HeJin |
|---|---|---|---|
| Certification: | Calibration Certificate(Cost Additional) | Model Number: | HJ134 |
|
Detail Information |
|||
| Number Of Stations: | 6 Stations | Control Method: | PLC |
|---|---|---|---|
| Display Method: | Touch Screen | Voltage: | AC220 |
| Main Frame: | Aluminum Profile | Closure Panel: | White Sheet Metal |
| Highlight: | AC220V Leak Testing Equipment,Airtightness Testing Leak Testing Equipment |
||
Product Description
AC220V Aluminum Copper Valve Core Airtightness Testing Machine of Leak Testing Equipment
Product Introduction with Leak Testing Equipment:
This equipment is used to test the sealing performance of copper valve cores. The workstation has six operating stations, which inflate the valve cores with high and low-pressure gases to determine if there are any leaks through the system.
Product Parameters with Leak Testing Equipment:
| Number of Stations | 6 Stations |
| Test Pressure |
0-0.6Mpa (adjustable air pressure) with two test pressure lines, one ranging from 0-0.6Mpa (kg), and the other ranging from 0-0.05Mpa. Both pressure lines can automatically switch based on the test. |
| Control Method | PLC |
| Transmission Method | Cylinder, motor (servo system must utilize a hybrid control method with speed, position, and torque capabilities to control the rotation speed and torque at extreme positions) |
| Display Method | Touch Screen |
| Voltage | AC220 |
| Airtightness Evaluation | Pressure sensor pressure drop method (one pressure sensor for the inlet and one for the outlet) |
| Main Frame | Aluminum Profile |
| Closure Panel | White Sheet Metal |
Product Image with Leak Testing Equipment:
Our advantage service:
We have our own developing and designing team, which ensure our own technological and innovative products for customers.
For any customers who have new idea about some products, just let us know, we can according to your idea provide a unique design of the products.
Technical support:
All our workers are experienced and skilled.
After sale service:
Our working team and sales teams can guarantee a fast and high efficiency after-sale service for our product sold to everywhere of the global.
About Us:
Guangzhou Hejin Automation Control Technology Co., Ltd. is a modern enterprise specialized in the research and development, manufacturing, and sales of technology-intensive industrial equipment. The company's leading products include vacuum helium leak detection equipment, automatic brazing machines for gas/liquid filling and recovery systems, lean production lines, and laboratory testing equipment. These products are widely used in industries such as automobiles, refrigeration, power, home appliances, electronics, pharmaceuticals, plumbing, military, and others. Led by Mr. Li Jianhe, an expert with profound knowledge in vacuum and automated testing equipment, the company possesses its own core technology and holds multiple invention and utility model patents. Relying on a high-level talent team, the company has adopted a new production model focused on development and design, assembly and debugging, as well as after-sales service, and provides products that are suitable for customers' specific usage and technical requirements. Since its establishment, the company has introduced various types of specialized equipment to the market, satisfying domestic market demand while also exporting to countries and regions in America, Europe, Asia, and Africa.
