Ceramic Component Helium Detection System 1*10-8 Pa·M3/S Leak Rate

Product Description

Ceramic Component Helium Detection System 1*10-8 Pa·m3/s

Ceramic Component Helium Detection System 1*10-8 Pa·m3/s Leak Rate

Introduction of Ceramic Component Helium Detection System:

The ceramic component leak detection system uses a touch screen and button switches for display and control. The workpiece is manually placed, and one product is tested at a time. Different specifications of products are tested by changing the leak detection fixture. During system leak detection, the workpiece to be inspected is manually placed on the leak detection fixture, which is connected to the leak detector through the leak detection switching valve. After the workpiece security positioning, the cylinder descends and pushes the helium nozzle to compress the workpiece. Then start the auxiliary pump and start vacuuming the interior of the workpiece. Then the leak detector continues to evacuate and clear the background. When the leak detector reaches the background value, the equipment sprays helium gas. The leak detector makes a leakage rate judgment based on the penetration of helium gas.

Feature of Ceramic Component Helium Detection System:

1. Helium mass spectrometer leak detector: leak detection equipment, including two parts: host and mechanical pump

2. Leak detection tooling: Customized matching fixtures for different products, including island valves, air circuits, machined parts, etc

3. Electric control system: Implement one click operation of the entire leak detection system, automatically completing the leak detection process, including switch buttons, touch screen, etc

4. Pneumatic actuator: including air source processing accessories, valves, cylinders, pipelines, joints, etc

Parameter of Ceramic Component Helium Detection System:
