SUS304 Dust Test Chamber For Road Vehicles Determining Degrees Of Protection Against Foreign Objects 5k

Name: SUS304 Dust Test Chamber For Road Vehicles Determining Degrees Of Protection Against Foreign Objects 5k
Brand: HJ AUTOMATIC CONTROL TECHNOLOGY CO., LTD
SKU: HH0810A
Availability: InStock

Brand Name:	HeJin
Model Number:	HH0810A
MOQ:	1 Set
Price:	Negotiatable
Payment Terms:	T/T, L/C
Supply Ability:	5 set per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Third party calibration certificate(cost additional)

Product Name:

Sand And Dust Test Chamber HH0810A

Test Sample:

Electric And Electronic Components In Road Vehicles

Temperature Range:

RT+10-70°C

Inner Size:

W2000*D1000*H1000mm

Test Dust:

Talcum Powder

Vacuum Range:

0-10.0Kpa Adjustable

Inner Material:

SUS304 Stainless Steel Plate

Standard:

ISO 20653, IEC 60529

Packaging Details:

Plywood

Highlight:

SUS304 Dust Test Chamber

ISO 20653 Dust Test Chamber

PLC Dust Test Chamber

Product Description

Dust Chamber For Road Vehicles Determining Degrees Of Protection Against Foreign Objects 5k And 6k

Standard:

ISO 20653-2013 Road vehicles — Degrees of protection (IP code) — Protection of electrical equipment against foreign objects, water and access, figure 1- Principle test set-up for determining the protection against dust in vertical orientation; degree of protection against foreign objects 5K and 6K; Auto Parts Test Equipment

IEC 60529 Degrees of protection provided by enclosures (IP Code) clause 13.4, dust test for first characteristic number 5 and 6.

Parameter:

Inner size	W2000D1000H1000mm (can be customized)
Inner material	SUS304 stainless steel plate. Auto Parts Test Equipment
Square-meshed sieve	Nominal wire diameter is 50μm, nominal width of a gap between wires is 75μm
Control system	PLC and touch screen intelligent control system
Controller	programmable controller (this controller has the following functions of arbitrary setting) 1. blowing dust time (stop, blowing) can be adjusted 2. Cycle period: arbitrarily adjustable 3. Preset test time: 0s ~ 999h99m99s, adjustable 4. Power on: off-on-off
Temperature sensor	PT100 test sensor
Door	Tempered glass door

SUS304 Dust Test Chamber For Road Vehicles Determining Degrees Of Protection Against Foreign Objects 5k 0
