Wedge-Shaped Test Finger Probe for Document Shredder Safety | IEC 61032 & EN 60950 Compliance Testing Tool – Precision Stainless Steel Probe 25mm × 80mm

Name: Wedge-Shaped Test Finger Probe for Document Shredder Safety | IEC 61032 & EN 60950 Compliance Testing Tool – Precision Stainless Steel Probe 25mm × 80mm
Brand: HJ AUTOMATIC CONTROL TECHNOLOGY CO., LTD
SKU: HT-U14
Availability: InStock

Brand Name:	HJ
Model Number:	HT-U14
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	T/T
Supply Ability:	100 sets/ month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

TUV、ITS、CSA、BV、SGS 、CNAS(cost additional)

Material:

Stainless Steel / Insulated Handle

Overall Length:

80 Mm ±0.2 Mm

Probe Length:

50 Mm ±0.1 Mm

Standards Compliance:

IEC 61032, IEC 62368-1, EN 60950-1

Packaging Details:

Aluminum Box

Highlight:

stainless steel test finger probe

document shredder safety probe

IEC 61032 compliance testing tool

Product Description

Wedge-Shaped Test Finger Probe for Document Shredder Safety | IEC 61032 & EN 60950 Compliance Testing Tool – Precision Stainless Steel Probe 25mm × 80mm

Product introduction:

When it comes to checking if office gadgets are safe, like paper shredders and printers, you gotta look at everything. Our Wedge-Shaped Test Finger Probe (Model HT-U14) is made to be super exact and last long. It's built to act like a human finger touching these machines, so we can see if they're safe.

By acting like someone using the device, this probe lets companies find problems early, keep people safe, and pass safety checks worldwide, such as IEC 62368-1 and EN 60950.

Made with care from great stainless steel, the HT-U14 works the same every time, won't rust, and is sized just right. It's a must-have for anyone checking safety, whether in labs or factories.

Features:

Precision Design: Manufactured with strict dimensional tolerances to ensure accurate simulation of real human interaction.
Durable Construction: Made from corrosion-resistant stainless steel, offering long service life and consistent performance.
Ergonomic Handle: Designed for comfortable and stable operation, reducing testing fatigue.
IEC & EN Standard Compliance: Fully aligned with IEC 62368-1 and EN 60950-1 testing requirements.
High Repeatability: Guarantees reliable and reproducible testing outcomes.

International standards

The HT-U14 Test Finger Probe is manufactured in full accordance with the following international safety standards and testing clauses:
IEC 62368-1: Clause 8.6.3 – Accessibility of moving parts
EN 60950-1: Clause 2.1.1.1 – Accessibility to hazardous mechanical parts
IEC 61032: Test Probe 11 – Wedge-shaped test finger

Technical Specifications

Item	Specifications
Product Name	Wedge-Shaped Test Finger Probe
Model	HT-U14
Probe Shape	Wedge-shaped
Material	Stainless steel / Insulated handle
Overall Length	80 mm ±0.2 mm
Probe Length	50 mm ±0.1 mm
Probe Width	25 mm ±0.1 mm
Wedge Angle	30° ±1°
Handle Material	Insulated ABS / Aluminum alloy
Standards Compliance	IEC 61032, IEC 62368-1, EN 60950-1
Applications	Document shredders, printers, mechanical safety testing
Calibration Accuracy	±0.01 mm
Weight	180 g ±5 g
Surface Finish	Mirror polished anti-rust finish
Operating Temperature	0°C ~ 50°C
Storage Temperature	-20°C ~ 70°C
Customizability	Yes (custom dimensions available)

Product Specification Diagram:

Product detail images:
