600V Flammability Testing Equipment Button Operation Comparative Tracking Index Tester

Detail Information

Place of Origin:

China

Certification:

Calibration Certificate(cost additional)

Name:

Comparative Tracking Index Tester

Usage:

Flammability Tester,Flame Testing Equipment

Warranty:

12 Months

Testing Voltage:

0～600V Adjustable

Control Operation Mode:

Electrical Control, Button Operation

Electrode Material:

Platinum Electrode

Packaging Details:

Plywood

Highlight:

Product Description

Comparative Tracking Index Tester Flammability Testing Equipment Button Operation

Standard of Comparative Tracking Index Tester:

IEC60112-2009 Method for the determination of the proof and the comparative tracking indices of solid insulating materials.

IEC 60335-1 Household and similar electrical appliances – Safety –Part 1: General requirements clause Annex N Proof tracking test.

Application of Comparative Tracking Index Tester:

It is used to evaluate the comparative tracking index (CTI) values and proof tracking index (PTI) of the material.

Parameter of Comparative Tracking Index Tester:

ParametersModel	LT-2(0.5m³)
Working voltage	220V/50Hz, 1KVA
Control operation mode	Electrical control, button operation
Testing voltage	0～600V adjustable, precision 1.5％
Timing device	9999X0.1S
Electrode	Material: Platinum electrode and brass connecting rod
Electrode	Size: (5±0.1)×(2±0.1)×(≥12)mm, 30°slant, Tip rounding:R0.1mm
Relative position of electrode	Included angle: 60°±5°, distance is 4±0.1mm
Electrode pressure	1.00N±0.05N(digital display is optional)
Dripping liquid	The interval time of dropping liquid: 30±5S, digital display, can be preset
	Height: 35±5mm
	The number of drips:0-9999 times, can be preset, the volume size of the dripping liquid is controlled by the imported micro pump within 50 ~ 45 drips /cm³
Test liquid resistance	A liquid 0.1%NH4Cl, 3.95±0.05Ωm, B liquid 1.7±0.05Ωm
Time-delay circuit	2±0.1S (in 0.5A or larger current)
Short-circuit pressure drop	1±0.1A 1％, pressure drop 8% MAX
Wind speed	0.2m/s
Environmental requirement	0～40℃, relative humidity≤80%, in the place of no obvious vibration and corrosive gas
Dimensions and weight	WDH=1100×550×1200 mm, about 130kg
