Vertical Burning Test Apparatus with 1100° Temperature Resistance and 9mm Copper Block for IEC 60332 Compliance

Brand Name:	HeJin
Model Number:	VF-1
MOQ:	1 Set
Price:	Negotiatable
Payment Terms:	T/T,L/C
Supply Ability:	5 set per month

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin:

China

Certification:

Calibration Certificate(cost additional)

Copper Block:

9mm In Diameter, 10 ± 0 .05g Before Drilling

Temperature Resistance:

1100°

Product Name:

Flammability Test Chamber

Standard:

IEC 60332

Function:

Single Cable Burning Test

Metallic Screen:

H1200mm*W300mm*D450mm

Fixed Horizontal Support Of The Sample:

2, Distance:550mm

Gas:

>95% Propane Or Coal Gas

Packaging Details:

Plywood

Highlight:

1100° Temperature Resistance Vertical Burning Test Apparatus

9mm Copper Block Flammability Testing Equipment

220V/50Hz Operation Flammability Test Chamber

Product Description

Vertical Burning Test Apparatus for Single Wire & Cable | Flammability Testing Equipment for IEC & UL Compliance

Vertical Burning Test Apparatus is a professional flammability testing solution designed for single insulated wires and cables. Manufactured by HongCe, a trusted original factory in China, this device helps engineers assess flame propagation, after-burning, and after-glow performance in accordance with global safety standards. Stable, precise, and easy to operate, it is widely used in laboratories, compliance departments, and cable manufacturers.

Applications

Cable and wire factories
Electrical accessory manufacturers
Household appliance industry
Automotive cable production
Aerospace and railway wiring materials

International Standards

IEC 60332-1-1 / IEC 60332-1-2: Tests on electric and optical fibre cables under fire conditions -- Part 1
UL 2556: Wire and Cable Test Methods

Technical Parameters

Working voltage	220V/50Hz
Control operation mode	Electrical control, button operation
Blast burner standard	IEC60695-11-2 Annex A, Burner opening:Φ7±0.05mm, made of brass
Gas flow and gas category	Mixture gas:650±30mL/min propane; 10±0.5L/min air, Dual flow meter adjustment
Burning time	9999X0.1S
Burning angle	Tilt 45°±2°, Adjustable
Test flame calibration	Temperature measuring copper head:1000W:Ф9mm±0.01mm, weight before drilling:10 ± 0 .05g
Thermocouple	The American original Omega φ0.5 armour nickel-chromium/nickel aluminum wire K-Thermocouple, temperature resistance 1100°
Distance between the bunsen burner port to temperature measuring copper block	95 mm
Flame height	Inner flame:55±5mm, Outer flame:180±10mm
Temperature rise time from 100±5°C to 700°±3°C	45±5s
Metallic screen size	H1200mmW300mmD450mm
Combustion chamber	1 m³
Gas	>95% propane or coal gas
Test sample	Length:600±25㎜, distance from the bottom:50mm
Fixed horizontal support of the sample	2, distance:550mm

Test Objects

Single insulated wires
Small-size cables
Optical fiber cables
PVC/XLPE insulated conductors
Low-smoke zero-halogen (LSZH) cables

Test Capabilities

Flame propagation measurement
After-flame time
After-glow time
Dripping performance
Material carbonization length
Ignition resistance
Combustion behavior analysis

Product Image
