IEC60112 CTI PTI Flammability Testing Equipment PLC Control

Minimum Order Quantity : 1 set Price : Negotiable
Packaging Details : Plywood Delivery Time : 30 days
Payment Terms : L/C, T/T Supply Ability : 15 set per month
Place of Origin: China Brand Name: HeJin
Certification: Calibration Certificate(cost additional) Model Number: LT-3

Detail Information

Standard: IEC 60112 Usage: Flame Testing Equipment
Electrode Pressure: 1.00N±0.05N Electrodes Size: (5 ± 0,1 ) Mm × (2 ± 0,1 ) Mm
Drops Intervals: 30 S ± 5 S Drops Height: 35 Mm ± 5 Mm
Test Voltage: 0-600V Adjustable Name: Comparative And Proof Tracking Indices Test Apparatus
High Light:

PTI Flammability Testing Equipment

,

IEC 60112 Flammability Testing Equipment

,

PLC Flammability Testing Equipment

Product Description

IEC60112 CTI And PTI Flammability Testing Equipment PLC Control



Standard:

IEC60112-2009 Method for the determination of the proof and the comparative tracking indices of solid insulating materials.

It specifies the method of test for the determination of the proof and comparative tracking indices of solid insulating materials on pieces taken from parts of equipment and on plaques of material using alternating voltages. Flammability Testing Equipment



comparative tracking index

CTI

numerical value of the maximum voltage at which five test specimens withstand the test period for 50 drops without tracking failure and without a persistent flame occurring and including also a statement relating to the behaviour of the material when tested using 100 drops



proof tracking index

PTI

numerical value of the proof voltage in volts at which five test specimens withstand the test period for 50 drops without tracking failure and without a persistent flame occurring



Parameter:

ParametersModel LT-3(0.5m³) (Touch screen)
Working voltage 220V/50Hz, 1KVA
Control operation mode PLC control, 7 inch color touch screen operation, with infrared remote control
Testing voltage 0~600V adjustable, precision 1.5%
Timing device 9999X0.1S
Electrode Material: Platinum electrode and brass connecting rod
Size: (5±0.1)×(2±0.1)×(≥12)mm, 30°slant, Tip rounding:R0.1mm
Relative position of electrode Included angle: 60°±5°, distance is 4±0.1mm
Electrode pressure 1.00N±0.05N, Touch screen display
Dripping liquid The interval time of dropping liquid: 30±5S, digital display, can be preset
Height: 35±5mm
The number of drips:0-9999 times, can be preset, the volume size of the dripping liquid is controlled by the imported micro pump within 50 ~ 45 drips /cm³
Test liquid resistance A liquid 0.1%NH4Cl, 3.95±0.05Ωm, B liquid 1.7±0.05Ωm
Time-delay circuit 2±0.1S (in 0.5A or larger current)
Short-circuit pressure drop 1±0.1A 1%, pressure drop 8% MAX
Wind speed 0.2m/s. Flammability Testing Equipment
Environmental requirement 0~40℃, relative humidity≤80%, in the place of no obvious vibration and corrosive gas
Dimensions and weight WDH=1100×550×1200 mm, about 130kg



IEC60112 CTI  PTI Flammability Testing Equipment PLC Control 0
