5rpm Household Appliance Test Equipment Free Fall Repeated 500mm For Mechanical Strength Testing

5rpm Household Appliance Test Equipment Free Fall Repeated 500mm For Mechanical Strength Testing

Brand Name:	HeJin
Model Number:	HC9922
MOQ:	1 Set
Price:	Negotiatable
Payment Terms:	T/T, L/C
Supply Ability:	10 set per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Third party calibration certificate/ CE(cost additional)

Product Name:

TUMBLING BARREL TESTING MACHINE

Rotate Speed:

5rpm

Falls Rate:

10 Cycles Per Min

Number Of Falls:

0~9999 Times

Height Of The Falls:

500mm

Barrel Number:

Single

Pull Force Frequency:

1 Times/s

Standard:

IEC60335-1, IEC60068-2-31

Packaging Details:

Plywood

Highlight:

5rpm Household Appliance Test Equipment

1 Times/s Household Appliance Test Equipment

IEC 60335-1 Household Appliance Test Equipment

Product Description

Household Appliance Test Equipment Free Fall Repeated 500mm For Mechanical Strength Test

Standard:

IEC 60335-1 ‘Household and similar electrical appliances – Safety – Part 1: General requirements’ clause Annex B 21.101;

IEC60068-2-31 ‘Environmental testing - Part 2-31: Tests - Test Ec: Rough handling shocks, primarily for equipment-type specimens’.

Application:

It is used to check the drop resistance of electrical accessories, to assess the effects on a specimen of simple standard tests intended to be representative of the fall likely to be experienced during rough handling, or to demonstrate a minimum degree of robustness, for the purpose of assessing safety requirements. Household Appliance Test Equipment

Standard description:

The specimen shall be placed in the test apparatus and subjected to the prescribed number of falls. If the specimen is normally attached to a cable, the relevant specification shall state the type of cable to be used. When the specimen is normally attached to a cable, a free length of 100 mm of cable shall remain connected to the specimen during the test, unless otherwise prescribed in the relevant specification.

Parameter:

Model	HC9922
Rotate speed	5rpm
Falls rate	10 cycles per min
Material	Sideways 1.5mm high-quality steel plate, upper and lower are 3mm steel pads in the 10-19mm woods, and oblique part slide surface is plastic laminate, with triangle rubber pad
Number of falls	0~9999 times
Height of the falls	500mm. Household Appliance Test Equipment
Barrel number	Single
Dimension	WDH=630mm x 600mm x 1250mm
Chute Length	275mm
Application	Plug and socket and similar electrical accessories
Power supply	AC220V, 50Hz
