20r/Minute 50HZ Mechanical Drop Device Electrical Appliance Tester

Name: 20r/Minute 50HZ Mechanical Drop Device Electrical Appliance Tester
Brand: HJ AUTOMATIC CONTROL TECHNOLOGY CO., LTD
SKU: HJ0611
Availability: InStock

Brand Name:	HeJin
Model Number:	HJ0611
MOQ:	1 Set
Price:	Negotiatable
Payment Terms:	T/T, L/C
Supply Ability:	10 set per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Third party calibration certificate/ CE(cost additional)

Product Name:

Motorized Cleaning Heads Drop Device Test Equipment HJ0611A

Input Power:

AC220V 50HZ

Drive Mode:

Electric Moto Driven

Test Cycles:

1~999999, Adjustable

Working Speed:

≤20 R/minute

Dropping Height:

100mm

Standard:

IEC 60335-2-3

Function:

Household Appliance Test Equipment

Packaging Details:

Plywood

Highlight:

50HZ Mechanical Drop Device

50HZ Electrical Appliance Tester

20r/Minute Mechanical Drop Device

Product Description

Household Appliance Test Motorized Cleaning Heads Drop Device Test Equipment With 20 r/minute Working Speed

Standard:

IEC 60335-2-3 Household and similar electrical appliances – Safety: Part 2-3: Particular requirements for Vacuum cleaners and water-suction cleaning appliances.

Application:

It is used to test the mechanical strength of the motorized cleaning heads of water-suction cleaning appliances.

Test sample:

Motorized cleaning heads of water-suction cleaning appliances.Household Appliance Test

Feature:

Hang up the motorized cleaning heads of water-suction cleaning appliances, and make the control device is horizontal to the bottom plate, then drop from a height of 100 mm and fall to a rigid support plate which is at least 15 mm thick, with mass at least 15kg, process the test 4000 cycles at the speed of no exceed 20 cycles per min. It is dropped

--1000 times on its right side;

--1000 times on its left side;

--1000 times on its front face;

--1000 times on its cleaning surface;

Parameters:

Parameters / Model	HJ0611A Household Appliance Test
Input Power	AC220V 50HZ
Drive Mode	Electric moto driven, the drop action is achieved through the cam mechanism.
Test Cycles	1~999999, adjustable
Working Speed	≤20 r/minute
Dropping Height	100mm
Dropping Face	right side, left side, front face, cleaning surface, process 1000 cycles for each side
Support Steel Plate	Thickness >15mm, weight >15kg
Dimension & Weight	6006001250mm,120kg
