Home Appliances Cordless Kettle Endurance Test Equipment Voltage Output 0-250V
Contact Person : Tessa Huang
Phone Number : +86 18027403449
WhatsApp : +8618027403449
| Minimum Order Quantity : | 1 Set | Price : | Negotiatable |
|---|---|---|---|
| Packaging Details : | Plywood | Delivery Time : | 30 days |
| Payment Terms : | T/T, L/C | Supply Ability : | 10 set per month |
| Place of Origin: | China | Brand Name: | HeJin |
|---|---|---|---|
| Certification: | Third party calibration certificate/ CE(cost additional) | Model Number: | HJ0613 |
|
Detail Information |
|||
| Product Name: | Cordless Blender / Iron / Kettle Insert And Withdraw Endurance Tester HJ0613 | Control: | Electrical Control/PLC Control |
|---|---|---|---|
| Test Station: | Single Station | Drive Method: | Motor-driven |
| Test Sample: | Cordless Appliances | Test Cycles: | 0-999999 |
| Standard: | IEC60335-2-3, IEC60335-2-14, IEC60335-2-15 | Function: | Household Appliance Test Equipment |
| Highlight: | Insert And Withdraw Endurance Tester,AC220V Withdraw Endurance Tester |
||
Product Description
Household Appliance Test Equipment Insert And Withdraw Endurance Tester For Cordless Appliances
Standard:
IEC 60335-2-3 ‘Household and similar electrical appliances – Safety – Part 2-3: Particular requirements for electric irons clause 22.105.
IEC 60335-2-14 ‘Household and similar electrical appliances – Safety – Part 2-14: Particular requirements for kitchen machines’ clause 22.103.
IEC 60335-2-15 ‘Household and similar electrical appliances – Safety – Part 2-15: Particular requirements for appliances for heating liquids’ clause 22.103.
Application:
Cordless irons, cordless blenders, cordless kettles, cordless coffee makers and other cordless appliances shall be constructed to withstand the stresses occurring during normal use. Household Appliance Test Equipment
The connection contacts of cordless irons shall be constructed so that any electrical or mechanical failure occurring in normal use will not give rise to a hazard.
The appliance coupler of cordless appliances shall be constructed to withstand the stresses occurring during normal use.
The appliance coupler of cordless blenders shall be constructed to withstand the stresses occurring during normal use.
Feature:
The two live pins of the appliance are connected together and an external resistive load is connected in series with the supply. The external load is such that the current is 1.1 times rated current. The appliance is placed on its stand and withdrawn at a rate of approximately 10 times per minute.
Test sample:
Cordless irons, cordless blenders, cordless kettles, cordless coffee makers and other cordless appliances
Parameter:
| Parameters / Model | HJ0613 | HJ0613A, Household Appliance Test Equipment |
| Input Power | AC220V 50HZ | AC220V 50HZ |
| Control | Electrical control, Buttons operation | PLC control, touch screen operation |
| Station | Single station | Single station |
| Drive Method | motor-driven | motor-driven |
| Test Sample | Cordless kettle | Cordless water kettle/iron/blender |
|
Insert & Plug Stroke
|
100mm | 0-100mm, can be preset on touch screen |
| Insert & Plug Speed | 0-30cycles/min, frequency control | 0-30 times/min, can be preset on touch screen |
| Test Cycles | 0-999999, can be preset | 0-999999, can be preset on touch screen |
| Conduction Cycles | 0-999999, can be displayed | 0-999999, can be displayed |
| Mechanical action | insert & plug action | insert & plug action and kettle switch open and close movement |
| Load | External 0-250V, 0-15A | Built-in 0-250V, 0-15A |
| Sample judgment | Judge conduction according to the current | Judge conduction according to the current |
| Dimensions and Weight | 1000×500×1200mm, 130kg | 1000×500×1200mm, 200kg |
