HeJin is the source manufacturer of IEC 60529 EV charger IP test chamber. All-in-one dust & waterproof testing machine for charging pile certification. Free test proposal & global after-sales support. Get your quote now.

Product Description

As global EV charging infrastructure expands rapidly, outdoor charging piles must withstand heavy rain, splashing water and blowing sand. Failed IP certification will delay your product launch and cause costly field warranty claims. Reliable ingress protection testing is essential for your product certification and field safety. HeJin designs and manufactures professional waterproof level testing equipment, built to verify IP dust and water resistance for electric vehicle chargers. As an original source manufacturer, we manage full-cycle R&D, production and after-sales service, delivering stable, traceable IP test chambers for manufacturing factories and independent testing laboratories.

Product Introduction

Outdoor EV chargers face rain, splashing water, dust and sand every single day. Without rigorous IP rating verification, field failures, premature aging and safety risks will emerge after installation. Our EV charger IP dust & waterproof level testing equipment is engineered to simulate real-world harsh environmental conditions. The integrated chamber combines dust circulation and multi-angle water spray testing in one single unit. It can complete IPX5, IPX6 waterproof and IP5X, IP6X dust protection tests for charging stations, charging guns and charging control modules.

HeJin is the source manufacturer. We do not act as resellers. Our in-house engineering team completes all design, mechanical processing, assembly and calibration work. We understand the pain points of EV hardware manufacturers: long delivery lead times, inconsistent test data, complicated equipment maintenance and poor after-sales support. This IP test chamber solves those challenges, delivering repeatable and traceable test results for your product certification.

Product Features

• All-in-one integrated chamber: combines dust resistance and water ingress testing in one cabinet, saving your lab space and equipment investment.
• Multi-angle adjustable water jet nozzles, precisely simulating rain, splash and high-pressure water spray conditions.
• Closed-loop dust circulation system, stable dust concentration for repeatable dust ingress tests.
• Intelligent PLC touchscreen control system, programmable test duration, pressure and dust concentration parameters.
• Full sealed chamber structure, anti-leakage water drainage system, easy sample loading and unloading.
• Calibrated sensor modules, real-time monitoring of water pressure, dust concentration and chamber temperature.

Applicable International Standards

1. IEC 60529: Degrees of protection provided by enclosures (IP Code)
   • IPX5: Protection against water jets projected by a nozzle from any direction.
   • IPX6: Protection against powerful high-pressure water jets from any direction.
   • IP5X: Protection against dust ingress; limited dust penetration allowed, no harmful deposit.
   • IP6X: Dust-tight, no dust ingress into the enclosure.
2. IEC 61851: Electric vehicle conductive charging system
   • Specifies IP rating requirements for EV charging stations and charging couplers.
3. ISO 16750: Road vehicles – Environmental conditions and testing for electrical and electronic equipment
   • Defines environmental test requirements for vehicle charging electrical components.

Technical Parameters

Product Application

This IP test chamber is widely used for product development, type testing, batch sampling inspection and third-party certification testing for EV charging equipment. EV charger manufacturers can verify new product design reliability before mass production to avoid large-scale field failure risks. Independent third-party testing laboratories can carry out standard IP rating certification tests for global client projects. Automotive R&D institutes rely on this equipment for environmental reliability research of charging components. Meanwhile, quality inspection departments adopt it for regular incoming and finished product quality audit, ensuring consistent product quality standards.

Test Objects & Test Items

Test Objects

• AC & DC EV charging stations / charging piles
• EV charging guns and charging connectors
• Charger control modules and power cabinets
• EV charging terminal electronic assemblies
• Outdoor charging related electrical enclosures

Available Test Items

• IPX5 water jet test
• IPX6 high pressure water spray test
• IP5X dust ingress test
• IP6X dust tightness test
• Combined dust & water sequential ingress protection test

Detail pictures

FAQ

Q1: What IEC 60529 IP ratings can EV charger waterproof level testing equipment perform?
A1: Our professional IP test chamber covers full IEC 60529 ingress protection tests, including IPX5, IPX6 high-pressure water spray tests and IP5X, IP6X dust tightness tests, fully compliant for EV charging piles, charging guns and charging module certification.

Q2: Can this IP test chamber test both complete charging piles and small charging gun samples?
A2: Yes. Equipped with adjustable universal sample fixtures, the equipment supports full-size outdoor charging stations, portable charging connectors and compact control module samples for flexible batch testing.

Q3: Does this equipment provide valid test data for third-party certification?
A3: Yes. All test data is real-time recorded, traceable and fully compliant with IEC 60529 and IEC 61851 standards, widely accepted by global third-party testing and certification institutions.

Q4: Is custom chamber size and fixture design available for special samples?
A4: Customization is fully supported. Our in-house R&D team can tailor chamber dimensions, internal layout and clamping fixtures according to your unique product specifications.

Q5: What is the standard production lead time for this IP test equipment?
A5: Standard model lead time is 30 working days after deposit. Customized solutions will be scheduled and confirmed in the formal quotation.

Q6: Do you provide overseas installation and technical training?
A6: Yes. We offer global on-site commissioning, equipment calibration and operator training services to ensure smooth local operation.

Q7: Why choose an all-in-one IP test chamber over separate dust and water test machines?
A7: The integrated design saves 50%+ lab space and reduces procurement costs. It ensures consistent test environments and simplifies daily operation and maintenance compared with two separate devices.
