Automatic Test Cycle High Recovery Rate Helium Leak Detection System With Leak Testing Equipment

Product Description

Automatic Test Cycle High Recovery Rate Helium Leak Detection System With Leak Testing Equipment

Product Introduction with Leak Testing Equipment:

According to the basic principle of helium leak detection, helium is used as a tracer gas to charge helium into the workpiece, and then the accuracy of workpiece leakage can be quickly and accurately determined by helium leak detector.

Installation Requirements with Leak Testing Equipment:

The installation can only be conducted by trained professional installers.

The installation of the equipment at the site requires the following conditions:

(1) Main Power Supply

Electrical parameters: three-phase five-wire 380VAC, power 15KW.

Switches: 8 air switches, with a height above ground of ≥1.5M and a distance to the main equipment placement position of ≤2M.

(2) Gas Supply

① Helium: ≥1 bottle of bottled helium (40 liters 12MPa) with a 0.1MPa pressure reducing valve;

② High-purity nitrogen: bottled high-purity nitrogen (≥99.999%) with a 0.2MPa pressure reducing valve;

③ Compressed air: clean compressed air with a pressure of 0.55-0.7MPa;

The distance between the gas supply interfaces and the placement position of the machine should be ≤1M.

(3) Others

① Prepare an outdoor exhaust pipe with a diameter of ≥3/4″, and the distance between the interface and the placement position of the machine should be ≤1M.

Product Parameters with Leak Testing Equipment:

Product Image with Leak Testing Equipment:

Our advantage service:

We have our own developing and designing team, which ensure our own technological and innovative products for customers.
For any customers who have new idea about some products, just let us know, we can according to your idea provide a unique design of the products.

Technical support:

All our workers are experienced and skilled.

After sale service:
Our working team and sales teams can guarantee a fast and high efficiency after-sale service for our product sold to everywhere of the global.


About Us:

Guangzhou Hejin Automation Control Technology Co., Ltd. is a modern enterprise specialized in the research and development, manufacturing, and sales of technology-intensive industrial equipment. The company's leading products include vacuum helium leak detection equipment, automatic brazing machines for gas/liquid filling and recovery systems, lean production lines, and laboratory testing equipment. These diverse products are extensively employed across industries ranging from automotive, refrigeration, power generation, household appliances, electronics, pharmaceuticals, plumbing systems, to military applications. Under the guidance of Mr. Li Jianhe, a seasoned expert with extensive expertise in vacuum and automated testing technologies, the company boasts proprietary core technologies and a substantial portfolio of invention and utility patents. Leveraging a high-caliber team of professionals, the company has embraced a novel production paradigm centered on development, design, assembly, debugging, and comprehensive after-sales support. This approach ensures that every product delivered is tailored to meet the unique usage scenarios and technical specifications of our clients.Since its establishment, the company has continuously introduced various types of special equipment to the market. While meeting the needs of the domestic market, it also exports to America, Europe, Asia, Africa and other countries and regions.
