Ф1600×H1000mm Hard Coating Film Coater 0~60RPM Vacuum Coating Machine KSL-1600

Minimum Order Quantity : 1 Set Price : Negotiatable
Packaging Details : Plywood Delivery Time : 90 Days
Payment Terms : L/C, T/T Supply Ability : 10 Set per month
Place of Origin: China Brand Name: HeJin
Certification: Calibration Certificate(Cost Additional) Model Number: KSL-1600

Detail Information

Chamber: Ф1600×H1000mm Workpiece Rack Rotation Speed: 0~60RPM (Adjustable)
Coating Chamber Pumping Speed: 3.0×10-3Pa≤30min Ultimate Vacuum Level: 8.0×10-5Pa
Coating System: DC, MF, Or RF Magnetron Sputtering Source Sputtering Target Materials: C, Si, Nb, Cr, Al, Ti, And Various Compounds
Film Thickness Control: Quartz Crystal Control Or Optical Control Control System: Industrial Control Computer + Touch Screen
High Light:

KSL-1600 Vacuum Coating Machine

,

0~60RPM Vacuum Coating Machine

,

Hard Coating Film Coater

Product Description

Hard Coating Film Coater



Application Range:

For various tools (milling cutters, drill bits, broaches, gear cutters, taps, etc.), precision molds, and other surface hard coating treatments.



Product Features:

This product combines precision-optimized magnetic and electric fields with advanced High Power Impulse Magnetron Sputtering (HIPIMS) and Chemical Vapor Deposition (CVD) technologies. It successfully achieves the density and smoothness of the film, while imparting high hardness, high toughness, and excellent adhesion to the substrate. These excellent characteristics jointly lay the foundation for the high performance of the product, providing stable and reliable solutions for various high-end applications.



Product Parameters:

Model KSL-1600
Chamber Size Ф1600×H1000mm
Workpiece Rotation Speed 0~60RPM (Variable)
Chamber Pumping Speed 3.0×10-3Pa ≤ 30min
Ultimate Vacuum Degree 8.0×10-5Pa
Coating System DC, MF, or RF Magnetron Sputtering Source
Sputtering Target Materials C, Si, Nb, Cr, Al, Ti, and Various Compounds
Film Thickness Control Crystal Control or Optical Control
Control System Industrial Computer + Touch Screen



Ф1600×H1000mm Hard Coating Film Coater 0~60RPM Vacuum Coating Machine KSL-1600 0Ф1600×H1000mm Hard Coating Film Coater 0~60RPM Vacuum Coating Machine KSL-1600 1Ф1600×H1000mm Hard Coating Film Coater 0~60RPM Vacuum Coating Machine KSL-1600 2



Our advantage service:

We have our own developing and designing team, which ensure our own technological and innovative products for customers.
For any customers who have new idea about some products, just let us know, we can according to your idea provide a unique design of the products.



Technical support:

All our workers are experienced and skilled.


After sale service:
Our working team and sales teams can guarantee a fast and high efficiency after-sale service for our product sold to everywhere of the global.



About Us:

Guangzhou Hejin Automation Control Technology Co., Ltd. is a modern enterprise specialized in the research and development, manufacturing, and sales of technology-intensive industrial equipment. The company's leading products include vacuum helium leak detection equipment, automatic brazing machines for gas/liquid filling and recovery systems, lean production lines, and laboratory testing equipment. These products are widely used in industries such as automobiles, refrigeration, power, home appliances, electronics, pharmaceuticals, plumbing, military, and others. Led by Mr. Li Jianhe, an expert with profound knowledge in vacuum and automated testing equipment, the company possesses its own core technology and holds multiple invention and utility model patents. Relying on a high-level talent team, the company has adopted a new production model focused on development and design, assembly and debugging, as well as after-sales service, and provides products that are suitable for customers' specific usage and technical requirements. Since its establishment, the company has introduced various types of specialized equipment to the market, satisfying domestic market demand while also exporting to countries and regions in America, Europe, Asia, and Africa.
