10KW 300V Load Bank For Externally Ballasted Lamp Loads IEC Test Equipment

Minimum Order Quantity :	1 set	Price :	Negotiatable
Packaging Details :	Plywood	Delivery Time :	30 days
Payment Terms :	L/C, T/T	Supply Ability :	10 set per month

Place of Origin:	China	Brand Name:	HeJin
Certification:	Third party calibration certificate(cost additional)	Model Number:	HC9915A

Detail Information
Product Name:	Load Bank	Working Station:	Single Station(2 Or 3 Stations Optional)
Output Voltage:	Range 0 ~ 300V	Output Current:	Range 0 ~ 30A
Power:	Range 0～10KW	Power Factor:	Range 0.3 ~ 0.999
Capacitance:	70uf, 140uf, 7.3uf Optional	Load Power Capacity:	2*10KVA
Highlight:	300V Load Bank , 10KW Load Bank , IEC Test Equipment Load Bank

Product Description

Load Bank For Externally Ballasted Lamp Loads IEC Test Equipment

Standard:

IEC 60884-1 'Plugs and socket-outlets for household and similar purposes – Part 1: General requirements' clause 19, clause 20;

IEC 60669-1 ‘Switches for household and similar fixed electrical installations – Part 1: General requirements’ clause 19.2

Application:

Switches intended for externally ballasted lamp loads shall withstand, without excessive wear or other harmful effect, the electrical and thermal stresses occurring when controlling externally ballasted lamp circuits. IEC Test Equipment

Parameter:

No	Item	Parameter
1	Power Supply	AC220, 50Hz.
2	Voltage V	Range 0 ~ 300V accuracy ± 05% ± 2d
3	Current A	Range 0 ~ 30A accuracy ± 05% ± 2d
4	Power KW	Range 0～10KW, accuracy±05%
5	Power Factor	Range 03 to 0999 accuracy ± 05% ± 2d
6	Load Selection	Resistive, Inductive and Capacitive load three in one, switchable
7	Capacitance Selection	70uf, 140uf, 7.3uf optional
8	Output Mode	Each power, Interval power optional
9	Count/Preset	0～999999 times, can be preset
10	Load power capacity	2*10KVA
11	Output current limit	30A, the load will be automatically cut off when over 32A
12	Output voltage limit	300V, the load will be automatically cut off when over 320V
13	Atmospheric pressure	80～106kpa
14	Ambient temperature	5～40°C IEC Test Equipment
15	Relative humidity	(20～90)%RH
16	Use environment	Requires no violent shaking, no vibration, no electromagnetic interference, no dust, no explosive, no corrosive gases, needs good heat dissipation place
