Nylon Handle UL 1278 Test Finger Probe Figure 8.1 PA130A PA140A

Brand Name:	HeJin
Model Number:	HT-U02, HT-U03
MOQ:	1 set
Price:	Negotiatable
Payment Terms:	L/C, T/T
Supply Ability:	100 sets / per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

calibration certificate (cost additional)

Product Name:

UL Test Probe

Standard:

UL1278 Movable And Wall- Or Ceiling-Hung Electric Room Heaters

Handle:

Nylon

Probe Material:

Stainless Steel

Figure 8.1:

Probe For Uninsulated Live Parts

Figure 8.2:

Probe For Film-coated Wire

Finger Length:

101.6mm

Application:

Accessibility Of Live Parts

Packaging Details:

Cartoon Box

Highlight:

Figure 8.2 Test Finger Probe

UL 1278 Test Finger Probe

PA140A Test Finger Probe

Product Description

UL 1278 Test Finger Probe Figure 8.1 (PA130A) and Figure 8.2 (PA140A)

Standard:

UL1278 Movable and Wall- or Ceiling-Hung Electric Room Heaters Figure 8.1 Probe for uninsulated live parts and Figure 8.2 Probe for film-coated wire.

Application:

It is used for the testing of coating lines of the enamel (i.e., transformers and inductors). And for the performance of the electrical equipment enclosure preventing electric shock.

Feature:

Nylon handle + probe, it is manufactured according to the standard figure. Test Finger Probe

Parameter:

Item	HT-U02
Finger length	101.6mm
Length 1	14.3mm
Diameter 1	12.7mm
Diameter 2	19.1mm
Item	HT-U03
Finger length	101.6mm
Diameter 1	12.7mm
Diameter 2	19.1mm

Nylon Handle UL 1278 Test Finger Probe Figure 8.1 PA130A PA140A 0

Figure 8.1 Probe for uninsulated live parts

Nylon Handle UL 1278 Test Finger Probe Figure 8.1 PA130A PA140A 1

Figure 8.2 Probe for film-coated wire
